AET ThinQ

AT Series

Specially manufactured for Broadcast & Media, B2B, Transportation, Control & Surveillance Centers, Government, and Healthcare & Hospitals, AT Series Elevates your visual impact with its exceptional clarity and color accuracy.

New Layer
Home 9 Product 9 At Series

Key Features

Your Image

Features

Features

DCP Technology

Features

HDR Technology

Features

Energy Saving Scheme

Features

Pleasant Viewing Experience

Features

DCP Technology

Features

HDR Technology

Popup Image

Specs

Physical Parameter Pixel pitch 0.9 mm
LED Type SMD 4-in-1 common cathode
Pixel Density (m2) 1,137,777 pixel/m2
Pixel Density (Cabinet) 58,9824 pixels/cabinet
Resolution of LED Module (W×H) 256×288 pixels
Resolution of Cabinet (W×H) 1024×576 pixels
LED Module Size (W×H) 240×270 mm
Cabinet Size (W×H×D) 960×540×27.2mm | 43 in
No. of Modules Per Cabinet (W×H) 8×3
Cabinet Area 0.5184 m2
Aspect Ratio 16:9
Weight (per cabinet) 11 kg
Cabinet Material Die-casting Aluminium/Aluminium-magnesium alloy
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio 7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 48
Colour Temperature – Adjustable 3200~9300 K
Electrical Parameter Average Power Consumption (W/m2) ≤150 W/m3
Max Power Consumption (W/m2) ≤650 W/m3
Input Power Voltage AC 100-240V, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) ≥3840 Hz
Grey Scale Processing 14-18 bit
Operational Conditions Operating Temp/Humidity -10 – 45°C/10% – 90% RH
Storage Temp/Humidity -20 – 60°C/10% – 90% RH
IP Rating IP5X
Life Span, typ 100,000 Hrs
Service Servicing Front


Physical Parameter Pixel pitch 1.06 mm
LED Type SMD 2-in-1 common cathode
Pixel Density (m2) 885,780 pixel/m2
Pixel Density (Cabinet) 518,400 pixels/cabinet
Resolution of LED Module (W×H) 120×180 pixels
Resolution of Cabinet (W×H) 960×540 pixels
LED Module Size (W×H) 127.5×191.2 mm
Cabinet Size (W×H×D) 1020×573.76×28.8mm | 46 in
No. of Modules Per Cabinet (W×H) 8×3
Cabinet Area 0.5852 m2
Aspect Ratio 16:9
Weight (per cabinet) 15.5kg
Cabinet Material Die-casting Aluminium/Aluminium-magnesium alloy
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio ≥7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 30
Colour Temperature – Adjustable 500 – 10000 K
Electrical Parameter Average Power Consumption (W/m2) ≤120 W/m3
Max Power Consumption (W/m2) ≤500 W/m3
Input Power Voltage AC 100-240V, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) ≥3840 Hz
Grey Scale Processing 14-18 bit
Operational Conditions Operating Temp/Humidity -10 – 45°C/10% – 90% RH
Storage Temp/Humidity -20 – 60°C/10% – 90% RH
IP Rating IP5X
Life Span, typ 100,000 Hrs
Service Servicing Front


Physical Parameter Pixel pitch 1.25 mm
LED Type COB 0406 common anode
Pixel Density (m2) 640,000 pixel/m2
Pixel Density (Cabinet) 518,400 pixels/cabinet
Resolution of LED Module (W×H) 120×135 pixels
Resolution of Cabinet (W×H) 960×540 pixels
LED Module Size (W×H) 150×168.75 mm
Cabinet Size (W×H×D) 1200×675×30.6mm | 54 in
No. of Modules Per Cabinet (W×H) 8×4
Cabinet Area 0.81 m2
Aspect Ratio 16:9
Weight (per cabinet) 18.5 kg
Cabinet Material Die-casting Aluminium/Aluminium-magnesium alloy
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio ≥7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 60
Colour Temperature – Adjustable 500 – 10000 K
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio ≥7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 60
Colour Temperature – Adjustable 500 – 10000 K
Processing Parameter Drive Mode Constant Current Drive
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) ≥3840 Hz
Grey Scale Processing 14-18 bit
Operational Conditions Operating Temp/Humidity -10 – 45°C/10% – 90% RH
Storage Temp/Humidity -20 – 60°C/10% – 90% RH
IP Rating IP5X
Life Span, typ 100,000 Hrs
Service Servicing Front


Physical Parameter Pixel pitch 1.26 mm
LED Type SMD 1010 common anode
Pixel Density (m2) 629,882 pixel/m2
Pixel Density (Cabinet) 518,400 pixels/cabinet
Resolution of LED Module (W×H) 240×135 pixels
Resolution of Cabinet (W×H) 960×540 pixels
LED Module Size (W×H) 302.4×170.1 mm
Cabinet Size (W×H×D) 1209.6×680.4×28.4mm | 55 in
No. of Modules Per Cabinet (W×H) 4×4
Cabinet Area 0.823 m2
Aspect Ratio 16:9
Weight (per cabinet) 18.5 kg
Cabinet Material Die-casting Aluminium/Aluminium-magnesium alloy
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio ≥7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 45
Colour Temperature – Adjustable 500 – 10000 K
Electrical Parameter Average Power Consumption (W/m2) ≤120 W/m3
Max Power Consumption (W/m2) ≤550 W/m3
Input Power Voltage AC 100-240V, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) ≥3840 Hz
Grey Scale Processing 14-18 bit
Operational Conditions Operating Temp/Humidity -10 – 45°C/10% – 90% RH
Storage Temp/Humidity -20 – 60°C/10% – 90% RH
IP Rating IP5X
Life Span, typ 100,000 Hrs
Service Servicing Front


Physical Parameter Pixel pitch 1.39 mm
LED Type SMD 1010 common anode
Pixel Density (m2) 514,484 pixel/m2
Pixel Density (Cabinet) 518,400 pixels/cabinet
Resolution of LED Module (W×H) 120×180 pixels
Resolution of Cabinet (W×H) 960×540 pixels
LED Module Size (W×H) 167×251.4 mm
Cabinet Size (W×H×D) 1336×754.2×28.8mm | 60 in
No. of Modules Per Cabinet (W×H) 8×3
Cabinet Area 1.008 m2
Aspect Ratio 16:9
Weight (per cabinet) 20kg
Cabinet Material Die-casting Aluminium/Aluminium-magnesium alloy
Optical Parameter Brightness – Adjustable 500-1000 nit adjustable
Contrast Ratio ≥7,000:1
Horizontal Viewing Angle ≥160°
Vertical Viewing Angle ≥160°
Scan Rate 60
Colour Temperature – Adjustable 500 – 10000 K
Electrical Parameter Average Power Consumption (W/m2) ≤120 W/m3
Max Power Consumption (W/m2) ≤500 W/m3
Input Power Voltage AC 100-240V, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) ≥3840 Hz
Grey Scale Processing 14-18 bit
Operational Conditions Operating Temp/Humidity -10 – 45°C/10% – 90% RH
Storage Temp/Humidity -20 – 60°C/10% – 90% RH
IP Rating IP5X
Life Span, typ 100,000 Hrs
Service Servicing Front
