DH Series

Captivate audiences in any environment. AET's DH Outdoor Series LED displays are engineered for exceptional durability and weather resistance, delivering superior visuals even in challenging conditions.

Home 9 Product 9 DH OUTDOOR

DH Indoor

DH Outdoor

Key Features

Image Hotspot Pointers
Your Image

Features

Features

WCG 100% Color Gamut

Features

Great Flatness

Features

Nanosecond Respond Time

Features

Seamless Splicing

Features

WCG 100% Color Gamut

Features

Great Flatness

Popup Image

Specs

Module Parameter LED Type SDM 2525/2727
Pixel pitch 6.0 mm
Module Resolution (W×H Pixel) 32×32
Module Dimension (mm) 192 (W)×192 (H)×15 (D)
Module Flatness (mm) ≤0.15
Pixel/m2 27,777
Servicing Front
Back Shell Plastic
Optical Parameter Single Dot Brightness Calibration Available
Single Dot Colour Calibration Available
Brightness (nits) 4000-4500
Colour Temperature (K) 1000-10000 – Adjustable
Viewing Angle (Horizontal/Vertical) 120°/120°
Brightness/Colour Uniformity ≥97%
Contrast Ratio 5000:1
Electrical Parameter Max Power Consumption (W/m2) ≤650
Average Power Consumption (W/m2) ≤150
Input Power Voltage AC110-220V± 15%, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive (common anode)
Frame Rate (Hz) 30-120 Hz
Refresh Rate (Hz) 1920-3840 Hz
Colour Depth (bits) 14-16 bit
Operational Parameter Life Span, typ. (Hrs) 100,000
Operating Temp (°C) -20 – 60
Storage Temp (°C) -20 – 60
Operating Humidity (RH) 10-90%
Storage Humidity (RH) 10-90%
Encapsulation Technology QCOB Available


Module Parameter LED Type Non-NS LED 2525 NS Copper LED 2525 NS GOLD LED 2525
Pixel pitch 8.0 mm
Module Resolution (W×H Pixel) 40×20
Module Dimension (mm) 320 (W)×160 (H)×15 (D)
Module Flatness (mm) ≤0.15
Pixel/m2 15,625
Servicing Rear
Back Shell Plastic
Optical Parameter Single Dot Brightness Calibration Depends on the individual project
Single Dot Colour Calibration Available
Brightness (nits) ≥5000
Colour Temperature (K) 1000-9500 – Adjustable
Viewing Angle (Horizontal/Vertical) 160°
Brightness/Colour Uniformity ≥97%
Contrast Ratio 5000:1
Scan Rate 4
Electrical Parameter Max Power Consumption (W/m2) ≤800
Average Power Consumption (W/m2) ≤235
Input Power Voltage AC110-220V± 15%, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive (common anode)
Frame Rate (Hz) 50-60 Hz
Refresh Rate (Hz) 3840 Hz
Colour Depth (bits) 16 bit
Operational Parameter Life Span, typ. (Hrs) 100,000
Operating Temp (°C) -20 – 60
Storage Temp (°C) -20 – 60
Operating Humidity (RH) 10-90%
Storage Humidity (RH) 10-90%
Encapsulation Technology QCOB Available


Module Parameter LED Type Non-NS LED 3535 NS Copper LED 3535 NS GOLD LED 3535
Pixel pitch 10.0 mm
Module Resolution (W×H Pixel) 32×16
Module Dimension (mm) 320 (W)×160 (H)×15 (D)
Module Flatness (mm) ≤0.15
Pixel/m2 10,000
Servicing Rear
Back Shell Plastic
Optical Parameter Single Dot Brightness Calibration Depends on the individual project
Single Dot Colour Calibration Available
Brightness (nits) ≥65000
Colour Temperature (K) 1000-9500 – Adjustable
Viewing Angle (Horizontal/Vertical) 160°
Brightness/Colour Uniformity ≥97%
Contrast Ratio 5000:1
Scan Rate 2
Electrical Parameter Max Power Consumption (W/m2) ≤800
Average Power Consumption (W/m2) ≤235
Input Power Voltage AC110-220V± 15%, 50/60 (Hz)
Processing Parameter Drive Mode Constant Current Drive (common anode)
Frame Rate (Hz) 50-60 Hz
Refresh Rate (Hz) 3840 Hz
Colour Depth (bits) 16 bit
Operational Parameter Life Span, typ. (Hrs) 100,000
Operating Temp (°C) -20 – 60
Storage Temp (°C) -20 – 60
Operating Humidity (RH) 10-90%
Storage Humidity (RH) 10-90%
Encapsulation Technology QCOB Available
